Customized auto wiring harness suitable for motor industry

Product Description

Mizu-P25 wire-to-wire connector system is the first miniature sealed system in the market to achieve IP67 certification, which provides superior levels of dustproof and waterproof protection along with space savings. The  IP67 rated, which ensures connector integrity when submerged in up to one meter of water, and  most common and popular used for e-bikes,lighting, mirror system and etc.

Product Details

01 Such mini-type waterproof IP67 connector special common used from molex and JST as below P/N.  With good advantages by Complete dustproof and waterproof protection.
The application for such cable assemblies with mini waterproof connectors:
 Automative:
 Door electronics
 Lamp mirrors
 Mirror motor harnesses
 Parking sensors
 Powered rear view mirrors
 Seating
 Steering
 Switches
 Wipers

 Commerical Vehicle:
  Boats
  Motorcycles
  Tractors
  E-bikes

Consumer:
   Air conditioner
   Heated toilet seats
   Vending Machines

 Industrial:
  LED lighting

02 Mizu-P25 Miniature Waterproof Connectors.  The Mizu-P25 family includes two sub-families: the low-voltage system, which is rated up to 125 volts; and the high-voltage system, rated up to 250 volts. Both versions of the Mizu-P25 family provide some of the smallest mated diameters of any similar system.This helps to meet the needs of makers in various industries to fit wire-to-wire solutions through smaller spaces, holes and hinges.

03 Ideal for applications such as motorcycles or air conditioners that continue to pack more complicated electronics into smaller spaces, the Mizu-P25 system provides assurance that dust or water will not interfere with signal integrity.

04 The Mizu-P25 family also includes features to make assembly easier for operators. This includes color coding of housings, low-insertion terminal design, easy-to-use positive-locks and polarization features to ensure correct mating. The features is positive locks ensure mating retention, integral seal stopper feature provides waterproof protection, spring-beam terminal desgin provides high pressure and small deflection for high-vibration applications, raised-body male terminal design provides polarization to prevent mismating.
