SAE black J1939M to J1939P cable assemblies

这里可以自定义设置
SAE black J1939M to J1939P cable assemblies
B站不支持收货地址
B站不支持库存规格
Model:
ETOP-2010-2
MOQ:
1000
Payment:
T/T 30% Prepayment, balance before delivery
Delivery Time:
4~6WKS
Start Port:
Shenzhen, Hongkong
Service:
OEM/ODM, Customizaion
Packing:
customized box, label and pallet
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
该产品后台详情无内容
这里可以自定义设置

Product Description

This adapter mates with a J1939 vehicle and allows an OBD2 style tester connection to fit. The J1939 +/- data lines are connected to the CAN +/- lines, and the power and ground lines are also connected. The most common application is to connect a GPS Tracker that is meant for an OBD2 vehicle to a vehicle that has the 9-pin round Deutsch connector.

J1939 is a set of standards that defines how information is transferred within a CAN to communicate information between ECUs. While a CAN provides a tool for communication, J1939 is a higher-layer protocol that provides a language for communicating using that tool. J1939 is specifically built to work with the CAN model, but codes messages in a way that is standardized for all users of the network, making it easier to communicate data efficiently and effectively.

Product Specifications

   PE, PP, SR-PVC, PVC..  26AWG, 24WG, 20AWG, 18AWG etc
Product NameSAE BLACK J1939M to J1939P cable assemblies
Application

Automobile diagnostic system

diesel trucks, buses, on-road vehicles, off-road vehicles,

marine propulsion, power generation, and industrial pumping

Cable colorPer customer requirements
Cable LengthPer customer requirements
Connector typej1939
Suitable Wire Gauge(terminals)26AWG, 24WG, 20AWG, 18AWG etc
Terminal materialsCopper&Tin
Quality CertificateISO9001, IATF16949, ROHS, UL,SGS, REACH
Performance Test:100% terminal inspection & 100% electric testing & 100% FQC & AQL=0.65
这里可以自定义设置

Product Details

这里可以自定义设置

01 Specification

    Accepts contact sizes 4 (100 amps), 12 (25 amps), and 16 (13 amps)
    Customized cable format is 6-20 AWG (16.00-0.50 mm2)
    6 and 9 cavity arrangements
    In-line, flange, or PCB mount
    Circular, thermoplastic housing
    Coupling ring for mating
    J1939 key arrangement
    Temp. Range: -67°F (-55°C) to 257°F (125°C)
    Available accessories: Backshells, boots, dust caps, gaskets, lanyards, mounting clips, strain relief
    Sealed military style housings have silicone elastomer seal and are threaded for demanding applications
    Smooth Diagnostic Grade housings are non-sealed for controlled applications
    Designed as a Deutsch HD series drop-in replacement

这里可以自定义设置

02    ETOP is professional in design and manufacture all kinds of special cables,have accumulated rich experience in development and production for kinds of wire harness and cable assembly, vehicle diagnostic cables,Telematics / CAN / Heavy Vehicle Cables and its related connector and adapter. We at OBD Diagnostics Inc have developed a software package for use with our OBD2allinone scan tool for J1939 data logging and diagnostics. The J1939 protocol is used for heavy vehicle and industrial applications, and is based on the OBD2 Controller Area Network, CAN, protocol used in all new vehicles.
A few of the myriad uses are:

    diesel powertrain systems
    on and off road gasoline powered vehicles
    liquid natural gas LNG vehicles
    agriculture and forestry machinery ISO 11783
    intra vehicle networking for trucks and buses
    power generation and industrial pumping
    truck-trailer communication
    recreational vehicles
    marine systems NMEA2000
    military vehicles MiLCAN
    fleet management systems

这里可以自定义设置

03  J1939 Cable - Manufacturing Solution

J1939-9Pin Type 2 splitter cable with Jamnut

J1939-9Pin Male to Female*2 cable

J1939 Splitter cable for Truck Trackig Device

J1939 Pass through cable for Truck Trackig Device

SAE J1939-9pin Pass through cable

J1939-9Pin Green Male+Female to OBD female cable

Heavy Vehicle J1939 9-Pin Telematics Cables

ELD cables
Telematics OBD GPS Tracking Cables
Automotive Diagnostic Cables
Automotive Diagnostic Adapters
Automotive Diagnostic Connectors
Custom Wire Harnesses and Adapter

Product Applications

Automobile series cable: kinds of high quality Telematics GPS tracking cable,OBD2 splitter "Y "cable,OBD2 J1962 test cable, Heavy Vehicle J1939&1708 eld cable, Vehicle Diagnostic equipment cable and its related Vehicle connector,adapter,plug and socket.
2. Custom OEM cable, wire harnesses & assembly, also can make all kinds of special using cables,connectors,adapters and mould developing.

    diesel powertrain systems
    on and off road gasoline powered vehicles
    liquid natural gas LNG vehicles
    agriculture and forestry machinery ISO 11783
    intra vehicle networking for trucks and buses
    power generation and industrial pumping
    truck-trailer communication
    recreational vehicles
    marine systems NMEA2000
    military vehicles MiLCAN
    fleet management systems
