Product Description
These cable assemblies applied for automobile, designed with auto wire, like TXL, GXL, TWP, AVS, AVSS. And related connectors are original from FCI, YAZAKI, SUMITOMO, MOLEX, TYCO. The complete auto wiring assemblies covered braiding sleeve or corrugated tube to protect wires, also 3M taped at both sides or branching point to fix.
| Product Name | Designing Wire Harness For Auto Rearview Mirror System | ||
| Application | Automative Rearview Mirror System | ||
| Cable color | Per customer requirements | ||
| Cable Length | Per customer requirements | ||
| Ｗires | GXL#16*2C+ #18*5C OS:9.3 PVC black 45P, core wire is low-halogen | ||
| Contact type | Receptacle | ||
| Pitch | 2.54mm | ||
| Circuts | 2-8 | ||
| Wire AWG | 18-22AWG | ||
| Contact Plating | Tin | ||
| Connector series | MX64 Molex | ||
| Material-Resin | PBT | ||
| Service | OEM and ODM products are acceptable | ||
| Samples | Samples confirmed first before mass production | ||
| Quality Certificate | ISO9001, IATF16949, ROHS, UL,SGS, REACH | ||
| Performance Test: | 100% terminal inspection & 100% electric testing & 100% FQC & AQL=0.65 | ||
01This Molex MX64 connectors 31402-2500, is 2.54mm MX64 Sealed Single Row Crimp Housing, GET Terminal, Black, 2 Circuits, Key B, without CPA Lock. OEM-approved and USCAR-compliant compact MX64 Sealed Connectors offer features that provide a secure connection for rugged automotive applications, including a version designed for seamless mating with a variety of LED modules
Small and compact, the MX64 single row female connectors set the standard for 2.54mm pitch sealed connectors that are available in a variety of sizes. These connectors allow for the greatest level of flexibility by accommodating three different female terminal systems.
02 Molex's MX64 Sealed Connectors for LED modules feature TPA with a high-retention force that provides electrical reliability in rugged environments. A wide latch provides an audible click to ensure secure mating, which eliminates the time required to check connection quality as well as guarding against end-product failures. The housings are available in different color and key options, providing polarization which helps to minimize the mismating.
Application:
Automotive
Body Electronics
Comfort, infotainment, and driver assist
Power Train
Safety / Chassis
Commercial Vehicle
Hydraulics
Powertrain
Safety / Chassis
Meeting OEM-approved and USCAR-compliant requirements, compact MX64™ connectors provide seamless mating possibilities with a variety of automotive sensors, Molex's MX64 series sets the standard for 2.54 mm pitch sealed connectors.
03 TE Connectivity's (TE) .040 MULTILOCK Series incorporates contacts and connectors designed to be used in automotive applications. They can be used in Wire-to-Wire or Wire-to-board applications and the available number of positions range from 2-64. The contacts for the .040 MULTILOCK Series are available in several finishes and accept a wire range from 22-14 AWG.
Features
Contacts are spaced at 2.5 mm centerline
Connectors are consisted of plug housings, receptacle contacts for wire termination, and cap housing assemblies for horizontal and vertical mountings on PC boards
The contacting point of a receptacle contact is designed to be protected
The plug housings are provided with double-lock mechanism integrated into the body which ensures complete contact insertions into housings
Specifications
Contact Material: Brass, Phosphor bronze
Contact Finish: Pre-Tin, Selective Gold
Wire Range Size: 24-16 AWG
No. of Positions for Wire-to-Wire: 2, 3, 4, 6, 8, 10, 12, 14, 18, 20, 30
No. of Positions for Wire-to-Board: 3, 6, 8, 10, 12, 14, 18, 20, 24, 30, 42
We provide wiring harness manufacturing services for cable assemblies and built-to-print cables used in many industries, such as computer, game machine, POS machine, ATM, audio/video, electro-mechanical, data communications, telecommunications, medical, etc.
