Product Description
Most of our customers are OEMs or ODMs in USA, Germany, Japan, Australia, Sweden, etc. Etop has their special sampling production line， also with fully-equipped internal tooling department for SR, connector, plastic part, or any other tooling parts efficiently. And our dedicated team can support customers with much more suggestions and techinics for developing their new products. All these can help customers shorten the L/T a lot with most competitive tooling and sampling cost.
| Product Name | Custom auto Wire Assembly with MCP connector | |||
| Application | Automative, Industry | |||
| Cable color | TXL Wire is available in solid colors and stripes with optional custom printing and/or numbering available. | |||
| Cable Length | Per customer requirements | |||
| Wire Insulation | Cross-Linked Polyethylene (XLPE) | |||
| Specification(Cables) | Ford Specification: | Ford (M1L-123A) | ||
| Chrysler Specification | Chrysler (MS-8288) | |||
| SAE Specification | SAE J-1128 | |||
| Number of positions | 12,25,36, | |||
| Connector Pitch | 2.8mm | |||
| Operating Temperature Range | -40. 120℃ | |||
| Cable Jacket | XLPE Insulation Jacket(Black) | |||
| Connectors type | Hybrid, Housing for male terminals, Wire-to-Wire, 12 Position, 5mm [.197in] Centerline, Green, Signal | |||
| Pin out connection | As per customer’s request | |||
| Inner Copper | Tinned Copper | |||
| Great Quality | The durable relay and heavy duty relay socket with wires are made by high-grade materials to ensure superior quality. | |||
| Quality Certificate | ISO9001, IATF16949, ROHS, UL,SGS,ROHS,REACH | |||
| Performance Test: | 100% terminal inspection & 100% electric testing & 100% FQC & AQL=0.65 | |||
01
We have wide range of materials source, also we can support customers to make a customized one to replace the original ones per customer need. We could supply different options for customer, such as DEUTCH, JST, TE, MOLEX, KST,CINCH,DELPHI and so on.
For this automative wire harness, we usually use AMP TYCO components, AMP MCP connectors and contacts are designed for electronic and electrical applications in motor vehicle, including long term use in high vibration, high current and high ambient temperature applications. un-sealed connector housing, called 1-967627-1. it belongs to AMP MCP 2.8,AMP MCP Connector system. it is housing for male terminals, with 2.8mm pitch, wire-to-wire system, 12positions for connectors,and also other more positions available, just for your choose and use, the nominal voltage 12v,24v, is for signal circuit applications . AMP MCP housing connectors feature 1-92 cavity arrangements available with a locking latch or lever latch mating mechanism. AMP MCP housings accepts size 9.5, 6.3/4.8K, 2.8 and 1.5K contacts, carrying up to 100 amps.
02
All these components that we use is comply with the substance restrictions of the Restriction on Hazardous Substances Directive 2011/65/EU (RoHS2). The RoHS2 Directive requires that certain electrical and electronic equipment products do not contain mercury, cadmium, hexavalent chromium, PBB, PBDE, lead, DEHP, BBP, DBP and DIBP above defined thresholds. Products indicated as 'Compliant' do not contain any of these substances above the prohibition thresholds. Finished electrical and electronic equipment products will be CE marked as required by the Directive. Components may not be CE marked.
These products comply with the substance restrictions of the End of Life Vehicles Directive 2000/53/EC (ELV). The ELV Directive requires that materials and components of vehicles do not contain mercury, cadmium, hexavalent chromium, and lead above defined thresholds. Products indicated as 'Compliant' do not contain any of these substances above the prohibition thresholds
03
There is also micro-fit connector used in the automative wiring harness. Micro-Fit Power Connector System, is available in multiple circuit sizes and cable lengths for power applications, offer a 3.00mm pitch, an 8.5A maximum current rating and many design options such as a terminal position assurance, blind-mating and compliant pin features. The Micro-Fit Connector Family offers up to 8.5A with a 3.00mm pitch, delivering power in a compact package in wire-to-wire and wire-to-board configurations. OEMs often need power connectors in space-constrained applications.
Micro-Fit 3.0 BMI Connectors are designed for blind-mating applications. They allow mating misalignment (per product drawing). In hard-to-reach applications, such as drawers or fan assembly trays, connectors need to be mated and unmated without being seen. Doing so can cause damage to the connector and/or terminal and consume valuable labor time.
We specialize in custom harnesses for the widest diversity of cable and connector types, across the whole spectrum of industries. We built your unique Molded Cable Assemblies according to your specified shapes, sizes, pin configuration and cable materials to suit Ethernet, Automation, Marine, truck, bus, ebikes, vehicle, Transportation Applications…etc.
