Product Description
This OEM/ODM Wire Harness Assy With ECU Sealed Connector used for automobile industry. The type connector is original one by waterproof type with seal.
This custom electric cable assemblies assembled with TE AMPSEAL connectors. The cables processed following by IPC620 standard strictly, and the dedicated team can support customers with much more suggestions and techniques for developing new products efficiently. All these can help customers shorten the L/T a lot with most competitive cost and stable quality. ETOP has the Flexibility and Capacity to accommodate a product's life cycle, design through production. ETOP can work with Customer from a product's inception to ensure maximum performance at the lowest possible manufactured cost.
| Product Name | Local FCI APEX 2.8MM 14WAY CONNECTORS | ||
| Application | Automobile Connectors | ||
| Cable color | Per customer requirements | ||
| Cable Length | Per customer requirements | ||
| Connectors postion | 14 position | ||
| Connector type | Male | ||
| Suitable Wire Gauge(Connectors) | 20AWG to 12AWG | ||
| Connector series | APEX | ||
| Housing Materials | Polyamide(PA) | ||
| Materials | Ultramid A3EG7 Nylon 6/6 GF35 | ||
| Rows | 2 rows | ||
| Connector pitch | 5.25mm | ||
| Suitable Wire Gauge(terminals) | 20AWG to 18AW | ||
| Terminal materials | Copper&Tin | ||
| Quality Certificate | ISO9001, IATF16949, ROHS, UL,SGS, REACH | ||
| Performance Test: | 100% terminal inspection & 100% electric testing & 100% FQC & AQL=0.65 | ||
01 The connectors for Dashboard are TE original Superseal series, Part Ref 4-1437290-0 with 34 Position Rectangular Housing Connector Plug Black 0.118" (3.00mm). Superseal 1.0 plug housings accept 1.0 mm receptacle contacts, carrying up to 15 amps. They are available in 26, 34, and 60 way arrangements and have an integrated latch for mating.
Design for the automotive industry, AMP Superseal series connectors meet the sealing requirements outlined in IEC 529 and DIN 40050 IP 6.7 waterproof standard.
02 Dashboard wire harenss with automotive electric unit ECU connectors, which is for Wire-to-Board (1.0 mm, 3.00mm) and ECU applications, under hood or any location where sealing is required, suitable for automotive, truck, bus, or off-road vehicles.
ECU connectors, PCB headers, together with the aluminum boxes, which are all parts of an engine control unit, are a great advantage of our whole products range.
The advantages for the ECU connectors are compact system minimizes packaging requirements, sealing reliability proven under harsh conditions, designed for ease of manual harness assembly, engine mounting installed flexiably under hood environments for your vehicles.
03 This type of Ampseal automotive plug ASSEMBLIES came original from TYCO, which used for auto Powertrain systems, Safety and Security systems, or Body and Chassis systems. AMPSEAL receptacle housings are environmentally sealed and available in 8, 14, 23, and 35 cavity arrangements.They accept size 1.3 mm contacts (up to 17 amps gold, up to 8 amps tin) and feature an integrated latch for mating. TE Ampseal Ref P/N 770680-1 connector with 4mm pitch, 23pins with 3 rows, nominal voltage architecture 12v, 42v, 48v, 240v. Operating voltage 250VAC.
AMPSEAL automotive plug style receptacle housings with an IP67 rating, a 4mm centerline and mechanical and Colored keying. These AMPSEAL receptacle housings have a 2 piece contact holding design and secondary locking to prevent contact backout and accept a wire size of 0.5 to 1.25mm2.
We are more than your source for world-class automotive connectors technology. Innovating together, we work side-by-side with customers in virtually every industry to create answers to the connectivity challenges of tomorrow. We provides quality electrical and electronic interconnection products for automotive, on- and off-highway, and hybrid and electric vehicles to electrically and mechanically join wires and cables, printed circuit boards, integrated circuit packages, and batteries. Our automotive connectors are built to withstand tough conditions and suit the needs of varying industries
